Irancell Modem Wireless Configuration Guide

TDi40 Modem setting for WiFi connection:

• Connect modem to PC using LAN cable and enter 168.1.1 in the address bar of the browser. For username and password, enter: admin.
• Then, follow the path below:
• WiFi>Wireless>Basic and enter your desired name for WiFi in SSID section.
• Follow WiFi>Wireless>Security and enter your chosen password in Passphrase section.
• After each change, click Apply.
• Now, you can use the WiFi with the new data applied.

FD-i40 E2 Modem setting for WiFi connection:

• Connect the modem to PC using LAN cable or connect to modem through WiFi connection.
• Enter 168.1.1 in the address bar of the browser. In the main page, enter admin for both username and password and enter the management panel.
• From the left menu, choose WiFi or Wireless. In WiFi setting page, SSID field is for WiFi Network Name and Passphraseor Network Key field is for password.
• Enter the desired name for network in SSID and the new WiFi password in Passphrase.
• Click Apply or Save to save the changes.

Once the changes are applied, you can connect to WiFi network using new name and password.

FD-i40 B1 Modem setting for WiFi connection:

• Turn on the modem and connect to it using cable or through WiFi. Enter 168.1.1 in the address bar of the browser. Enter admin for both username and password.
• From the WiFi section, enter the Wireless Settings In this section, SSID field is for the name of Wireless Network and Passphraseor Network Key is for password.
• Enter your desired name in SSID and the new WiFi password in Passphrase

At the end, click on Apply or Save to save the changes.

FD-i40 B2 Modem setting for WiFi connection:

• Turn on the modem and get connected to it. Enter 168.1.1 in the address bar of the browser and for both username and password enter admin.
• From the settings menu, open the WiFi. In WiFi page, use SSID field for Network Name and Passphrase or Pre-Shared   Key for Wireless password.
• Enter the new name and password in these fields and click Apply to save the changes.

TF-5G G1  Modem setting for WiFi connection:

• Turn on the TF-5G G1 Modem and get connected to it via cable or through WiFi. Enter 168.1.1 in the address bar of the browser and for both username and password enter admin.
• After entering the management panel, search for Settings or Wireless Settings menu Settings ▶ WLAN ▶ WLAN Basic Settings
• In Network Name (SSID) field, enter your desired name for network and in WLAN key or Key Passphrasefield, enter the new password.
• Click Apply/Save to activate the new password.

B5142 Modem setting for WiFi connection:

• Connect the modem to PC using LAN cable. Enter 168.1.1 in the address bar of the browser and for both username and password enter admin.
• From the menu, select WIFI>Multiple SSID and in Network name (SSID), select the name of your wireless.
• In Authentication, select WPA2-PSK and in Key Passphrase, enter your desired password for wireless and press Apply. Now, you can use the WiFi with the new data applied.

DT350 Modem setting for WiFi connection:

• Connect the modem to PC using LAN cable. Enter 168.1.1 in the address bar of the browser and for both username and password enter admin.
• From the menu, select WIFI>Setting and in Network name (SSID), select the name of your wireless.
• In Authentication, select WPA2-PSK and in Key Passphrase, enter your desired password for wireless and press Apply.
• Now, you can use the WiFi with the new data applied.

GP2101  Modem setting for WiFi connection:

• Connect the modem to PC using LAN cable. Enter 168.1.1 in the address bar of the browser and for both username and password enter admin.
• From the menu, select WIFI>Setting and activate Enable WLAN and in SSID, select the name of your wireless.
• In Security, select WPA2-PSK and in Password, enter your desired password for wireless and press Submit.
• Now, you can use the WiFi with the new data applied.

GP2101 Plus Modem setting for WiFi connection:

• Connect the modem to PC using LAN cable. Enter 168.1.1 in the address bar of the browser and for both username and password enter admin.
• Follow this path: WiFi>Settings>Wireless Settings>Basic and in Network Name (SSID), enter your desired name for WiFi.
• Then, follow WiFi>Settings>Security and in Key Passphrase, enter your desired password.
• Press Apply after each change.
• Now, you can use the WiFi with the new data applied.

TK2510 Modem setting for WiFi connection:

• Connect the modem to PC using LAN cable. Enter 168.1.1 in the address bar of the browser and for both username and password enter admin.
• From the menu, select WiFi>Settings and in Network Name (SSID), enter your desired name for WiFi.
• In Authentication, select WPA2- PSK and in Key Passphrase, enter your desired password for wireless and click Apply.
• Now, you can use the WiFi with the new data applied.

TK2510 Plus Modem setting for WiFi connection:

• Connect the modem to PC using LAN cable. Enter 168.1.1 in the address bar of the browser and for both username and password enter admin.
• Follow this path: WiFi>Settings>Wireless Settings>Basic  and in Network Name (SSID) field enter your desired name for WiFi and in Key Passphrase, enter your desired password.
• Click Apply after each change
• Now, you can use the WiFi with the new data applied.

Z6000 Modem setting for WiFi connection:

• Connect the modem to PC using LAN cable. Enter 168.1.1 in the address bar of the browser and for both username and password enter admin.
• From the left menu, select WIFI>WLAN setting and activate Enable WLAN.
• In SSID, enter your desired name for wireless.
• In security, select WPA2-PSK and in Password, enter your selected wireless password and click Submit.
• Now, you can use the WiFi with the new data applied.
